Animal Treadmill (Disc Version)
清醒小鼠头固定跑步机（转盘版）
/1.jpg?v=r284z5)
/2.jpg?v=r284z5)
/3.jpg?v=r284z5)
/4.jpg?v=r284z5)
ST-DTM100
Product DescriptionAn innovative device designed specifically for awake animal experiments. By combining head fixation technology with a low-damping disc locomotion system, it provides an ideal solution for in vivo research on the relationship between brain function and behavior. Supports two-photon imaging, fiber photometry, and electrophysiology.
- Ultra-Thin Design: Only 54mm thick, easily fits under objectives, compatible with most multi-photon microscope systems.
- High-Stability Imaging: Secure fixation with imaging displacement controlled within 0.5μm.
- Comprehensive Functions: Integrated magnetic anesthesia box and temperature control module to ensure mouse physiological status.
- 4110.00 USD
- Inquire for Details *Get detailed quote or custom solution
Key Features & Advantages
Ultra-Thin Body & Microscope Compatibility
The overall device thickness is **only 54mm**. This ultra-thin design allows it to be easily placed under the objective lens, adapting to most space-constrained multi-photon microscope systems and leaving valuable operating space for optical imaging.
Height Adjustable Disc
The central knob allows for **0-10mm** height adjustment. This accommodates mice of different sizes, ensuring they are in the most natural and comfortable running posture, significantly improving experimental success rates.
Magnetic Anesthesia & Heating
Equipped with a magnetic anesthesia box providing a sealed environment for anesthesia gas. Built-in **temperature control module** (RT+5℃~45℃) effectively prevents hypothermia during long-term imaging or anesthesia, enabling full-process recording from awake to anesthetized states.
Technical Specifications
| Power Supply | AC 220V ±10% / 50Hz ±2% |
|---|---|
| Input Power | ≥ 30W |
| Temp Control Range | RT+5℃ ~ 45℃ (Accuracy ±1℃) |
| Adjustment Range | Lifting Height: 0 ~ 10mm (±2mm) |
| Dimensions | 300mm × 250mm × 54mm (±5mm) |
| Behavior Camera |
|
