Smart Sleep Deprivation System ST-SDA01 - Unique Anti-Climb Design & Precise Control

Smart Sleep Deprivation

智能睡眠剥夺仪

Anti-Climb Sleep Deprivation Demo

Model No.

ST-SDA01

Product Description

Designed for sleep research, drug development, and neural mechanism exploration. As core equipment for precise animal models, it solves the problem of animals "hugging the pole to rest" during long-term experiments, ensuring deprivation efficiency. Supports Manual, Circadian Rhythm, and EEG Closed-loop Trigger modes.

Innovative Anti-Climb: Conical design + rotating sleeves completely prevent mice from hugging the pole.
Multi-Modal Control: Supports Manual, Circadian Rhythm Timing, and TTL Signal External Trigger.
Modular Design: Deprivation chamber, food/water slots are fully detachable for easy cleaning and maintenance.

Key Features & Advantages

Innovative Anti-Climb Bar Design

Addressing the "pole-hugging" pain point common in ordinary devices, we designed a **conical anti-climb pole** and **external rolling sleeves**. During deprivation, mice cannot stand on the rotating bar or hug the center pole to rest, ensuring the validity of long-term experiments.

Flexible Multi-Mode Control

Features **Manual Mode** (for short-term experiments), **Circadian Mode** (supports 10 groups of time parameters to build jet-lag models), and **External Trigger Mode** (receives EEG/EMG TTL signals) to achieve precise closed-loop sleep deprivation.

Ultra-Compact & Modular

Compact size (330x448mm), fits directly into EEG monitoring boxes. Adopts a modular design where the **deprivation chamber, food/water slots, and LED modules** can be detached individually, greatly facilitating cleaning and sterilization after experiments.

Technical Specifications

Control Mode	Manual / Circadian (Timer) / External Trigger (TTL Input)
Bar Performance	Speed 0-30rpm, supports CW / CCW / Custom Loop
Experiment Duration	0 - 999 Hours
LED Control	• White Light: 0-1000lux adjustable • IR Light: 850nm Near-Infrared • Supports Independent Circadian Control
Power Supply	AC 220V (Built-in regulator)
Overall Dimensions	330mm × 448mm × 318mm
Chamber Dimensions	ID 320mm × OD 310mm × H 190mm
Language Support	Chinese / English
